Map Gesture Controls

Control web maps with hand gestures using your webcam. No mouse, no touch, no backend. Using MediaPipe hand-tracking WASM running entirely in the browser, users can pan a map with the left hand, zoom with the right hand, and rotate with both hands. Each action can be triggered with either a fist or a pinch -- whichever feels more natural. This makes maps accessible in kiosk and exhibit environments, enables hands-free interaction for users with limited mobility, and opens up novel touchless UI experiences. Camera data never leaves the device. 1. Webcam capture: GestureController opens the user's camera and feeds each frame to MediaPipe Hand Landmarker, which returns 21 3-D landmarks per detected hand. 2. Gesture classification: GestureStateMachine classifies each frame using classifyGesture(): left fist or pinch = pan; right fist or pinch = zoom (vertical movement); both hands active = rotate; anything else = idle. A configurable dwell timer (actionDwellMs, default 80 ms) prevents flickering, and a grace period (releaseGraceMs, default 150 ms) smooths gesture releases. 3. OL integration: OpenLayersGestureInteraction translates frame-over-frame hand deltas into ol/Map pan pixel offsets and zoom-level adjustments, applying dead-zone filtering and exponential smoothing before every update. Map Gesture Controls is the open-source project sanderdesnaijer/map-gesture-controls (https://github.com/sanderdesnaijer/map-gesture-controls) by sanderdesnaijer, released under MIT. Ion packages it unmodified from commit d8dd25ed4611, adding only a manifest, an icon and a storage compatibility script.

Written by sanderdesnaijer, published to Oikou by Ben Grande.

• ★ 103 stars on GitHub
• Licence: MIT
• Upstream version leaflet-v1.0.0
• Built from commit d8dd25ed4611

View the repository on GitHub
